eralytics flash point testers are renowned for their safe, fast, and precise measurements, providing a high-performance flash point testing solution for every application. The eraflash flash point testers are the future-proof replacement for D93 Pensky-Martens testers. By utilizing the continuously closed cup flash point testing standards ASTM D6450, ASTM D7094, ISO 24966 and IP 620, this innovative flash point testers ensure maximum safety and efficiency in the lab and the field.
Flash point testers perfectly tailored to your applications
Whether you’re in the fuel industry, the flavor and fragrance industry, the oil and gas industry or other related industries, we have the perfect solution for you. Get a glance in our eraflash Series Overview Brochure and see all flash point testers at a glance.
eraflash Series Overview Brochure
The ASTM D7094 flash point tester: A future-proof D93 replacement
ASTM D7094 flash point testing is the future-proof replacement for ASTM D93 Pensky-Martens testers, bringing 100% safety, unrivalled speed as well as best in class precision to your laboratory. With the wide temperature range of -40 °C to 420 °C (-40 °F to 788 °F) all kinds of liquids can be tested using only 1-2 ml of sample. Take your time and see why precision, safety & speed matters.
Best-in-class precision: Zero bias between D93 and D7094
In 2022, the most extensive ILS program of any flash point method to date was carried out with
commercial fuels, involving 20 laboratories and 25 different liquids according to ASTM D6300. These multiple interlaboratory studies (ILSs) have confirmed the exceptional performance of ASTM D7094. It offers outstanding precision across a wide temperature range, even when testing challenging or contaminated samples. Get more on this here:
| Material | Flash Point (°C) | ASTM D7094 R (°C) | ASTM D93 R (°C) | ASTM D56 R (°C) |
|---|---|---|---|---|
| Flavors & Fragrances | 23 | 2.0 | N/A | N/A |
| Jet Fuels | 40 | 2.6 | 2.8 | 3.1 |
| Diesel Fuels | 60 | 3.2 | 4.3 | 3.8 |
| Oil | 200 | 5.6 | 14.2 | N/A |
Ensuring regulatory compliance with every flash point tester
ASTM D7094 is accepted in the following fuel specifications: 100% safety with eraflash – The safe side of flash point testing
- Fuel oil (ASTM D396)
- Jet Fuel ( ASTM D1655)
- Diesel fuel (ASTM D975)
- Kerosene (ASTM D3699)
- Gas turbine fuel oil (ASTM D2880)
- Diesel fuel, Biodiesel blend (ASTM D7467)
100% safety with eraflash – The safe side of your flash point tester.
In contrast to Pensky Martens instruments the eraflash flash point tester series does not use an open flame. Instead, 2 pins create an electric arc that is used to ignite the sample inside a continuously closed chamber. Due to the small sample volume (1 ml or 2 ml) and the resulting low oxygen amount within the closed cup, the flame is automatically extinguished after ignition. The pressure increase in the closed cup following the ignition is used for the detection of the flash point. A pressure increase of ≥ 20 kPa is defined as a flash point by the method.
ASTM D6450, D7094, ISO 24966 and IP 620 are inherently safe continuously closed cup flash point (CCCFP) methods eliminating any fire hazard from your lab.
Unrivalled speed: Unmatched heating and cooling rates
The eraflash point tester utilizes the patented Peltier Boost Technology® (PBT) to significantly increase heating and cooling rates. With a sophisticated mechanism the Peltier elements are safeguarded from high temperatures during heat up and allows their use during cool down even at temperatures that would normally harm them. This eralytics’ innovation maximizes sample throughput by shortening the turnaround time of ERAFLASH.
Additionally PBT enables the eraflash point tester series to cover a temperature range of -25 °C to 420 °C within a single instrument. The new eraflash lt point tester was designed for faster flash point measurements at low temperatures. With its stacked Peltier design it reaches oven temperatures as low as -40 °C.
A reliable flash point tester for critical applications
Designed for robust performance in both laboratory and on-site environments, eraflash delivers reliable results even under harsh conditions. Based on ASTM D7094, its outstanding precision ensures accurate flash point measurements across a wide range of sample types. Trusted by leading organisations, including the US Navy, eraflash has proven itself to be a reliable solution for critical flash point testing worldwide.
