ERAVAP 2-in-1: Simultaneous measurement of VAPOR PRESSURE + DENSITY with a single, portable analyzer

A ground-breaking innovation for eravap is the optional combination with eralytics temperature-controlled U-tube density meter module DENS4052. This integrated ultra-light (< 1 kg!) density meter module (patented) offers density measurements in full compliance with ASTM D4052 & ISO 12185 (r = 0.00001 g/cm³).

eravap is now the only vapor pressure tester on the market which allows for simultaneous measurements of two parameters listed in international fuel specifications like ASTM D4814 and EN 228 in a single analyzer, namely the vapor pressure of gasoline according to ASTM D5191 and the density of gasoline, diesel or jet fuel according to ASTM D4052. Its portable and rugged design makes eravap the perfect solution for mobile laboratories, terminals, and field use.

For deeper insights into the simultaneous measurement of vapor pressure and density please download the latest application note “Combining Vapor Pressure & Density”.

scroll to see more images

• previous image
• next image

Unique X-oscillating metal U-tube design

The optional density meter module DENS4052 made from the special metal Hastelloy is based on an innovative X-oscillating U-tube where only the straight tubes of the U-tube are vibrating towards each other. In contrast to eralytics x-oscillating U-tube, traditional glass U-tube density meters oscillate in the Y-mode, requiring a heavy counterweight which makes them sensitive against external shocks and vibrations. eralytics’ innovative X-oscillating metal U-tube design is highly resistant against shocks and vibrations and makes it perfectly suitable for the measurement of all kinds of sample types also in the harshest conditions like directly in the field.

ERAVAP – Unique measuring options

The Vapor Pressure Tester eravap is available in two models. eravap (EV10) for vapor pressure testing of all kinds of liquids up to a max. vapor pressure of 1000 kPa (145 psi) and eravap lpg (EV20) for vapor pressure testing of LPG’s featuring an extended pressure range of up to 2000 kPa (290 psi). To complete your range of applications, eralytics offers a variety of unique measuring options for both ERAVAP models. Get an overview of the unique measuring options of eravap here >>

Low vapor pressure module

With eralytics optional LowVP Module (r<0.1 kPa) the measurement of low vapor pressure substances, like solvents or chemicals for MSDS purposes (material safety data sheets) or other official regulations (e.g. REACH) is an easy task. This method is based on the triple expansion method ASTM D6378 using eravap’s built-in high-performance shaker to ensure complete thermodynamic equilibrium at each expansion step, leading to an excellent correlation to the established but manual and time-consuming isoteniscope method ASTM D2879.

TVS™ – Temperature verification sensor for ASTM D5191 testing

One more great feature for eravap is the TVS™ – ASTM D5191 Temperature Verification Sensor (patented) for high precision vapor pressure testing of gasoline. This all-new temperature sensor allows easiest monitoring of the temperature directly in the sample container, featuring an immediate check of the sample preparation even before the actual measurement starts. TVS™ enables the specification of upper (and lower) temperature limits triggering an automatic warning, if the sample temperature does not match the requirements. Thus TVS™ is a very efficient tool helping you to save time and money while improving the quality control in your testing lab. Watch our latest video to get an overview of how the Temperature Verification Sensor TVS™ for eravap works: TVS Operation Video

scroll to see more images

• previous image
• next image

Maximum precision & accuracy

Recent improvements in the design of eravap led to an improved repeatability and reproducibility for vapor pressure testing. With a repeatability of only r ≤ 0.15 kPa and a reproducibility of R ≤ 0.50 kPa for ASTM D5191 and D6378 reference materials at 37.8 °C (100 °F) it clearly outperforms the precision statements of its own ASTM standards. Using ASTM D6378 instead of D5191 for vapor pressure testing additionally eliminates any operator bias caused by incorrect sample preparation needed only for ASTM D5191.

Please reference the graph for latest repeatability measurements of the latest eravap generation using cyclopentane and pentane at 37.8°C (100 °F).

scroll to see more images

• previous image
• next image

Outstanding design

With its quality-centric design eravap was not only designed for highest precision but also for highest durability. The self-lubricating piston and the powerful Peltier elements are the instrument’s centerpiece. It is built for highest sample throughput rates at minimum maintenance. Furthermore, recalibration of the instrument can be performed without any special tools or disassembling the unit.

eralytics patent pending Pure Sampling^TM technology minimizes the possiblity of cross contamination between measurements.

Range of applications

The area of applications ranges from freely programmable test methods for R&D labs to push-button simplicity. With its extended temperature range from -20 °C to 120 °C (4 °F to 248 °F) and V/L ratios ranging from 0.02/1 to 100/1 it can cope with the most difficult measurement scenarios as well as with routine analysis. Vapor pressure testing of up to 1000 kPa is possible. In combination with a 12 V DC adapter it can be even run by a vehicle battery, allowing vapor pressure testing in the field.

With its innovative design eravap is capable of measuring gasoline, oxygenated gasoline as well as any other solvent or even polymers. It is used worldwide by refineries, terminals, oil and pipeline companies as well as authorities and independent laboratories.

Option: 10-position autosampler for high sample throughput

eralytics’ 10-position autosampler is an optional accessory for the vapor pressure tester eravap. The 10-position autosampler is directly attached to the instrument allowing it to conveniently connect up to 10 samples simultaneously. It is the perfect solution for higher sample throughput and even more efficiency. All instruments maintain their portability, even with the 10-position autosampler attached.

.

High viscosity module

eravap already covers a wide range of applications with its standard configuration. However, if the viscosity of the samples increases it gets more difficult to draw them into the measurement cell. In such cases heating up the sample prior to introduction helps. During the measurement the sample sitting in the tubes will cool down potentially blocking them after the measurement.

eravap’s high viscosity extension heats the inlet and outlet as well as all transfer tubes up to 70 °C. The temperature is regulated to a defined value set in the measurement menu of the instrument. Using this module further extends the applicability of ERAVAP to a larger range of samples.

Measurement procedure

Beside sample preparation according to the relevant standards, just four easy steps are needed for high quality vapor pressure testing:

• Enter sample ID and operator name
• Select the measurement standard and add additional parameters when necessary
• Place the sample beside the analyzer and put the tubing inside the sample
• Press the RUN button

The instrument now visualizes the measurement procedure on the screen showing the sample and piston position, as well as the temperature and pressure within the measurement cell. The resulting vapor pressure is calculated according to the relevant standards and displayed.

scroll to see more images

• previous image
• next image

eravap feature video

• Unmatched temperature range, precision, speed and versatility
• Temperature range from -20 °C to 120 °C (-4 °F to 248 °F)
• Large variety of international standards and correlation methods available
• Pure Sampling^TM valve technology minimizes any cross-contaminations
• On-screen quality control mode
• Easy measurement of gasoline, crude oil, LPG and solvents

eravap operation video

Watch this video to get an overview on the standard operation of eravap: From installation to measurement and some extended measuring options.
